Across the last decade novel machine learning (ML) algorithms have been used to solve problems in computer vision, speech and language that were previously considered highly challenging. This has triggered an upsurge in interest in artificial intelligence (AI). These algorithms originated in the academic community but are now being deployed in real-world environments that differ considerably from their development domains in terms of scale, complexity, and dynamic nature. Real-world environments produce large amounts of heterogeneous, variable and high dimensional data that poses new challenges to the deployment of ML algorithms in real-world systems. These challenges are present along the whole ML algorithms workflow from data management to deployment, monitoring and redeployment of ML models.

Data Oriented Architecture (DOA) is an emerging software architecture pattern that aims to create data-driven, loosely coupled, decentralised, and open systems. DOA proposes to achieve such goals by exposing systems’ data as first class citizen to distributed, stateless, and asynchronous systems’ components. These design decisions enable DOA-based systems to achieve desirable properties such as data availability, reusability, and monitoring, as well as systems adaptability, scalability, and autonomy. Such properties have the potential to benefit the adoption and deployment of ML algorithms in real-world systems. For example, a DOA-based system can automatically store results from different treatments a data engineer applies to a data-set in the form of snapshots. An ML engineer can reuse these snapshots to select the most suitable ML model based on the available data. Similarly, the loosely coupled and asynchronous communication between system components in DOA can benefit the integration of ML algorithms into larger real-world systems.

This project aims to materialise these benefits in the form of architectural principles, as well as software tools that support the development, testing, deployment, and evolution of real world AI-based systems. We first focus on defining the DOA principles by surveying the design decisions that current research and industrial ML deployments have adopted to address the challenges that real-world systems pose. Then, we will design, implement, and evaluate software tools that enable the creation of systems that follow each identified principle.

Related Publications

An Empirical Evaluation of Flow Based Programming in the Machine Learning Deployment Context

Andrei Paleyes, Christian Cabrera, Neil D. Lawrence

1st International Conference on AI Engineering – Software Engineering for AI, :

Towards Better Data Discovery and Collection with Flow-Based Programming

Andrei Paleyes, Christian Cabrera, Neil D. Lawrence

Neurips Data-Centric AI Workshop (DCAI), :

Dataflow graphs as complete causal graphs

Andrei Paleyes, Siyuan Guo, Bernhard Schölkopf, Neil D. Lawrence

2nd International Conference on AI Engineering – Software Engineering for AI, :

Causal fault localisation in dataflow systems

Andrei Paleyes, Neil D. Lawrence

Proceedings of the 3rd Workshop on Machine Learning and Systems (EuroMLSys), :

Real-world Machine Learning Systems: A survey from a Data-Oriented Architecture Perspective

Christian Cabrera, Andrei Paleyes, Pierre Thodoroff, Neil D. Lawrence


Desiderata for next generation of ML model serving

Sherif Akoush, Andrei Paleyes, Arnaud van Looveren, Clive Cox

NeurIPS Workshop on Challenges in Deploying and Monitoring Machine Learning Systems (DMML), :
