Week 2: Basis Functions and Generalisation

[jupyter][google colab][reveal]

Neil Lawrence

Abstract:

This lecture will cover generalisation in machine learning.

ML Foundations Course Notebook Setup

We install some bespoke codes for creating and saving plots as well as loading data sets.

%%capture
%pip install notutils
%pip install pods
%pip install mlai

import notutils
import pods
import mlai
import mlai.plot as plot

Nonlinear Regression with Linear Models

Nonlinear Regression

We’ve now seen how we may perform linear regression. Now, we are going to consider how we can perform non-linear regression. However, before we get into the details of how to do that we first need to consider in what ways the regression can be non-linear. Multivariate linear regression allows us to build models that take many features into account when making our prediction. In this session we are going to introduce basis functions. The term seems complicted, but they are actually based on rather a simple idea. If we are doing a multivariate linear regression, we get extra features that might help us predict our required response varible (or target value), \(y\). But what if we only have one input value? We can actually artificially generate more input values with basis functions.

Non-linear in the Inputs

When we refer to non-linear regression, we are normally referring to whether the regression is non-linear in the input space, or non-linear in the covariates. The covariates are the observations that move with the target (or response) variable. In our notation we have been using \(\mathbf{ x}_i\) to represent a vector of the covariates associated with the \(i\)th observation. The coresponding response variable is \(y_i\). If a model is non-linear in the inputs, it means that there is a non-linear function between the inputs and the response variable. Linear functions are functions that only involve multiplication and addition, in other words they can be represented through linear algebra. Linear regression involves assuming that a function takes the form \[ f(\mathbf{ x}) = \mathbf{ w}^\top \mathbf{ x} \] where \(\mathbf{ w}\) are our regression weights. A very easy way to make the linear regression non-linear is to introduce non-linear functions. When we are introducing non-linear regression these functions are known as basis functions.

Basis Functions

Basis Functions

Here’s the idea, instead of working directly on the original input space, \(\mathbf{ x}\), we build models in a new space, \(\boldsymbol{ \phi}(\mathbf{ x})\) where \(\boldsymbol{ \phi}(\cdot)\) is a vector-valued function that is defined on the space \(\mathbf{ x}\).

Quadratic Basis

Remember, that a vector-valued function is just a vector that contains functions instead of values. Here’s an example for a one dimensional input space, \(x\), being projected to a quadratic basis. First we consider each basis function in turn, we can think of the elements of our vector as being indexed so that we have \[ \begin{align*} \phi_1(x) & = 1, \\ \phi_2(x) & = x, \\ \phi_3(x) & = x^2. \end{align*} \] Now we can consider them together by placing them in a vector, \[ \boldsymbol{ \phi}(x) = \begin{bmatrix} 1\\ x\\ x^2\end{bmatrix}. \] For the vector-valued function, we have simply collected the different functions together in the same vector making them notationally easier to deal with in our mathematics.

When we consider the vector-valued function for each data point, then we place all the data into a design matrix. The result is a matrix valued function, \[ \boldsymbol{ \Phi}(\mathbf{ x}) = \begin{bmatrix} 1 & x_1 & x_1^2 \\ 1 & x_2 & x_2^2\\ \vdots & \vdots & \vdots \\ 1 & x_n& x_n^2 \end{bmatrix} \] where here we are still considering the one dimensional input setting so \(\mathbf{ x}\) here represents a vector of our inputs with \(n\) elements.

Let’s try constructing such a matrix for a set of inputs. First of all, we create a function that returns the matrix valued function.

import numpy as np

def quadratic(x, **kwargs):
    """Take in a vector of input values and return the design matrix associated
    with the basis functions."""
    return np.hstack([np.ones((x.shape[0], 1)), x, x**2])

Functions Derived from Quadratic Basis

\[ f(x) = {\color{red}{w_0}} + {\color{magenta}{w_1 x}} + {\color{blue}{w_2 x^2}} \]

Figure: The set of functions which are combined to form a quadratic basis.

This function takes in an \(n\times 1\) dimensional vector and returns an \(n\times 3\) dimensional design matrix containing the basis functions. We can plot those basis functions against there input as follows.

The actual function we observe is then made up of a sum of these functions. This is the reason for the name basis. The term basis means ‘the underlying support or foundation for an idea, argument, or process,’ and in this context they form the underlying support for our prediction function. Our prediction function can only be composed of a weighted linear sum of our basis functions.

Quadratic Functions

Figure: Functions constructed by weighted sum of the components of a quadratic basis.

Choice of Basis

Our choice of basis can be made based on what our beliefs about what is appropriate for the data. For example, the polynomial basis extends the quadratic basis to aribrary degree, so we might define the \(j\)th basis function associated with the model as \[ \phi_j(x_i) = x_i^j \] which is known as the polynomial basis.

Polynomial Basis

The polynomial basis combines higher order polynomials together to create the function. For example, the fourth order polynomial has five components to its basis function. \[ \phi_j(x) = x^j \]

import numpy as np

import mlai

from mlai import polynomial

Figure: The set of functions which are combined to form a polynomial basis.

Functions Derived from Polynomial Basis

\[ f(x) = {\color{red}{w_0}} + {\color{magenta}{w_1 x}} + {\color{blue}{w_2 x^2}} + {\color{green}{w_3 x^3}} + {\color{cyan}{w_4 x^4}} \]

Figure: A random combination of functions from the polynomial basis.

To aid in understanding how a basis works, we’ve provided you with a small interactive tool for exploring this polynomial basis. The tool can be summoned with the following command.

Try moving the sliders around to change the weight of each basis function. Click the control box display_basis to show the underlying basis functions (in red). The prediction function is shown in a thick blue line. Warning the sliders aren’t presented quite in the correct order. w_0 is associated with the bias, w_1 is the linear term, w_2 the quadratic and here (because we have four basis functions) we have w_3 for the cubic term. So the subscript of the weight parameter is always associated with the corresponding polynomial’s degree.

Exercise 1

Try increasing the number of basis functions (thereby increasing the degree of the resulting polynomial). Describe what you see as you increase number of basis up to 10. Is it easy to change the function in intiutive ways?

Different Basis

The polynomial basis is widely used in Engineering and graphics, but it has some drawbacks in machine learning: outside the input region between -1 and 1, the values of the polynomial basis rise very quickly.

Now we look at basis functions that have been used as the activation functions in neural network model.

Radial Basis Functions

Another type of basis is sometimes known as a ‘radial basis’ because the effect basis functions are constructed on ‘centres’ and the effect of each basis function decreases as the radial distance from each centre increases.

\[ \phi_j(x) = \exp\left(-\frac{(x-\mu_j)^2}{\ell^2}\right) \]

import mlai

from mlai import radial

Figure: The set of functions which are combined to form the radial basis.

Functions Derived from Radial Basis

\[ f(x) = \color{red}{w_1 e^{-2(x+1)^2}} + \color{magenta}{w_2e^{-2x^2}} + \color{blue}{w_3 e^{-2(x-1)^2}} \]

Figure: A radial basis is made up of different locally effective functions centered at different points.

Rectified Linear Units

The rectified linear unit is a basis function that emerged out of the deep learning community. Rectified linear units are popular in the current generation of multilayer perceptron models, or deep networks. These basis functions start flat, and then become linear functions at a certain threshold. \[ \phi_j(x) = xH(x+ v_j) \]

import numpy as np

import mlai

from mlai import relu

Figure: The set of functions which are combined to form a rectified linear unit basis.

Functions Derived from Relu Basis

\[ f(x) = \color{red}{w_0} + \color{magenta}{w_1 xH(x+1.0) } + \color{blue}{w_2 xH(x+0.33) } + \color{green}{w_3 xH(x-0.33)} + \color{cyan}{w_4 xH(x-1.0)} \]

Figure: A rectified linear unit basis is made up of different rectified linear unit functions centered at different points.

Hyperbolic Tangent Basis

The rectified linear unit is a basis function that used to be used a lot for neural network models. It’s related to the sigmoid function by a scaling. \[ \phi_j(x) = \tanh(v_j x+ v_0) \]

import numpy as np

import mlai

from mlai import hyperbolic_tangent

Sigmoid or hyperbolic tangent basis was popular in the original generation of multilayer perceptron models, or deep networks. These basis functions start flat, rise and then saturate.

Figure: The set of functions which are combined to form a hyberbolic tangent basis.

Functions Derived from Tanh Basis

\[ f(x) = {\color{red}{w_0}} + {\color{magenta}{w_1 \text{tanh}\left(x+1\right)}} + {\color{blue}{w_2 \text{tanh}\left(x+0.33\right)}} + {\color{green}{w_3 \text{tanh}\left(x-0.33\right)}} + {\color{cyan}{w_4 \text{tanh}\left(x-1\right)}} \]

Figure: A hyperbolic tangent basis is made up of s-shaped basis functions centered at different points.

Fourier Basis

Joseph Fourier suggested that functions could be converted to a sum of sines and cosines. A Fourier basis is a linear weighted sum of these functions. \[ f(x) = w_0 + w_1 \sin(x) + w_2 \cos(x) + w_3 \sin(2x) + w_4 \cos(2x) \]

import numpy as np

import mlai

from mlai import fourier

Figure: The set of functions which are combined to form a Fourier basis.

In this code, basis functions with an odd index are sine and basis functions with an even index are cosine. The first basis function (index 0, so cosine) has a frequency of 0 and then frequencies increase every time a sine and cosine are included.

Functions Derived from Fourier Basis

\[ f(x) = {\color{red}{w_0}} + {\color{magenta}{w_1 \sin(x)}} + {\color{blue}{w_2 \cos(x)}} + {\color{green}{w_3 \sin(2x)}} + {\color{cyan}{w_4 \cos(2x)}} \]

Figure: A random combination of functions from the Fourier basis. Fourier basis is made up of sine and cosine functions with different frequencies.

Fitting Basis Function Models

Fitting to Data

Now we are going to consider how these basis functions can be adjusted to fit to a particular data set. We will return to the olympic marathon data from last time. First we will scale the output of the data to be zero mean and variance 1.

Olympic Marathon Data

Gold medal times for Olympic Marathon since 1896. Marathons before 1924 didn’t have a standardized distance. Present results using pace per km. In 1904 Marathon was badly organized leading to very slow times.

Image from Wikimedia Commons

The Olympic Marathon data is a standard dataset for regression modelling. The data consists of the pace of Olympic Gold Medal Marathon winners for the Olympics from 1896 to present. Let’s load in the data and plot.

%pip install pods

import numpy as np
import pods

data = pods.datasets.olympic_marathon_men()
x = data['X']
y = data['Y']

offset = y.mean()
scale = np.sqrt(y.var())
yhat = (y - offset)/scale

Figure: Olympic marathon pace times since 1896.

Things to notice about the data include the outlier in 1904, in that year the Olympics was in St Louis, USA. Organizational problems and challenges with dust kicked up by the cars following the race meant that participants got lost, and only very few participants completed. More recent years see more consistently quick marathons.

Exercise 2

Use the tool provided above to try and find the best fit you can to the data. Explore the parameter space and give the weight values you used for the

1. polynomial basis
2. Radial basis
3. Fourier basis

Write your answers in the code box below creating a new vector of parameters (in the correct order!) for each basis.

np.asarray([[1, 2, 3, 4]]).shape

Basis Function Models

\[ f(\mathbf{ x}_i) = \sum_{j=1}^mw_j \phi_{i, j} \]

\[ f(\mathbf{ x}_i) = \mathbf{ w}^\top \boldsymbol{ \phi}_i \]

Log Likelihood for Basis Function Model

The likelihood of a single data point given the model parameters is given by \[ p\left(y_i|x_i\right)=\frac{1}{\sqrt{2\pi\sigma^2}}\exp\left(-\frac{\left(y_i-\mathbf{ w}^{\top}\boldsymbol{ \phi}_i\right)^{2}}{2\sigma^2}\right). \] and making an assumption of conditional independence given the parameters we can write

to give us the likelihood for the whole data set.

Objective Function

Traditionally in optimization, we choose to minmize an object function (or loss function, or cost function) rather than maximizing a likelihood. For these models we minimize the negative log likelihood. This function takes the form,

\[ L(\mathbf{ w},\sigma^2)= \frac{n}{2}\log\sigma^2 + \frac{\sum_{i=1}^{n}\left(y_i-\mathbf{ w}^{\top}\boldsymbol{ \phi}_i\right)^{2}}{2\sigma^2}. \]

Design Matrices

We like to make use of design matrices for our data. Design matrices involve placing the data points into rows of the matrix and data features into the columns of the matrix. By convention, we are referincing a vector with a bold lower case letter, and a matrix with a bold upper case letter. The design matrix is therefore given by \[ \boldsymbol{ \Phi}= \begin{bmatrix} \mathbf{1} & \mathbf{ x}& \mathbf{ x}^2\end{bmatrix} \] so that \[ \boldsymbol{ \Phi}\in \Re^{n\times p}. \]

Multivariate Derivatives Reminder

To find the minimum of the objective function, we need to make use of multivariate calculus. The two results we need from multivariate calculus have the following form. \[\frac{\text{d}\mathbf{a}^{\top}\mathbf{ w}}{\text{d}\mathbf{ w}}=\mathbf{a}\] and \[\frac{\text{d}\mathbf{ w}^{\top}\mathbf{A}\mathbf{ w}}{\text{d}\mathbf{ w}}=\left(\mathbf{A}+\mathbf{A}^{\top}\right)\mathbf{ w}\] or if \(\mathbf{A}\) is symmetric (i.e. \(\mathbf{A}=\mathbf{A}^{\top}\)) \[\frac{\text{d}\mathbf{ w}^{\top}\mathbf{A}\mathbf{ w}}{\text{d}\mathbf{ w}}=2\mathbf{A}\mathbf{ w}.\]

Differentiate

Differentiating with respect to the vector \(\mathbf{ w}\) we obtain \[\frac{\text{d} E\left(\mathbf{ w},\sigma^2 \right)}{\text{d}\mathbf{ w}}=-\frac{1}{\sigma^2} \sum_{i=1}^{n}\boldsymbol{ \phi}_iy_i+\frac{1}{\sigma^2} \left[\sum_{i=1}^{n}\boldsymbol{ \phi}_i\boldsymbol{ \phi}_i^{\top}\right]\mathbf{ w}\] Leading to \[\left[\sum_{i=1}^{n}\boldsymbol{ \phi}_i\boldsymbol{ \phi}_i^{\top}\right]\mathbf{ w}^{*}=\sum_{i=1}^{n}\boldsymbol{ \phi}_iy_i.\]

Rewriting this result in matrix notation we obtain: \[ \sum_{i=1}^{n}\boldsymbol{ \phi}_i\boldsymbol{ \phi}_i^\top = \boldsymbol{ \Phi}^\top \boldsymbol{ \Phi}\] \[\sum _{i=1}^{n}\boldsymbol{ \phi}_iy_i = \boldsymbol{ \Phi}^\top \mathbf{ y} \]

Setting the derivative to zero we obtain update equations for the parameter vector and the noise variance. First to find \(\mathbf{ w}^{*}\) we solve \[ \left(\boldsymbol{ \Phi}^\top \boldsymbol{ \Phi}\right) \mathbf{ w}^{*} = \boldsymbol{ \Phi}^\top \mathbf{ y} \] and the update for \(\left.\sigma^2\right.^*\) is \[ \left.\sigma^2\right.^{*}=\frac{\sum_{i=1}^{n}\left(y_i-\left.\mathbf{ w}^{*}\right.^{\top}\boldsymbol{ \phi}_i\right)^{2}}{n}. \]

Wee should avoid solving these equations through direct use of the inverse. Instead we solve for \(\mathbf{ w}\) in the following linear system.

\[ \left(\boldsymbol{ \Phi}^\top \boldsymbol{ \Phi}\right)\mathbf{ w}= \boldsymbol{ \Phi}^\top \mathbf{ y} \] Compare this system with solve for \(\mathbf{x}\) in \[ \mathbf{A}\mathbf{x} = \mathbf{b}. \] For example see the numpy.linalg.solve or torch.linalg.solve.

But the correct and more stable approach is to make use of the QR decomposition.

We can now set up the system to solve with QR decomposition.

import pandas as pd
import mlai

poly_args = {'num_basis':4, # four basis: 1, x, x^2, x^3
             'data_limits':xlim}
Phi = pd.DataFrame(data = mlai.polynomial(x, **poly_args),
                   columns = [f'$x^{n}$' for n in range(poly_args['num_basis'])])

Solution with QR Decomposition

Performing a solve instead of a matrix inverse is the more numerically stable approach, but we can do even better.

The problems can arise with very large data sets, where computing \(\boldsymbol{ \Phi}^\top \boldsymbol{ \Phi}\) can lead to a very poorly conditioned matrix. Instead, we can compute the solution without having to compute the matrix. The trick is to use a QR decomposition.

A QR-decomposition of a matrix factorizes it into a matrix which is an orthogonal matrix \(\mathbf{Q}\), so that \(\mathbf{Q}^\top \mathbf{Q} = \mathbf{I}\). And a matrix which is upper triangular, \(\mathbf{R}\). \[ \boldsymbol{ \Phi}^\top \boldsymbol{ \Phi}\boldsymbol{\beta} = \boldsymbol{ \Phi}^\top \mathbf{ y} \] and we substitute \(\boldsymbol{ \Phi}= \mathbf{Q}\mathbf{R}\) so we have \[ (\mathbf{Q}\mathbf{R})^\top (\mathbf{Q}\mathbf{R})\boldsymbol{\beta} = (\mathbf{Q}\mathbf{R})^\top \mathbf{ y} \] \[ \mathbf{R}^\top (\mathbf{Q}^\top \mathbf{Q}) \mathbf{R} \boldsymbol{\beta} = \mathbf{R}^\top \mathbf{Q}^\top \mathbf{ y} \]

\[ \mathbf{R}^\top \mathbf{R} \boldsymbol{\beta} = \mathbf{R}^\top \mathbf{Q}^\top \mathbf{ y} \] \[ \mathbf{R} \boldsymbol{\beta} = \mathbf{Q}^\top \mathbf{ y} \] which leaves us with a lower triangular system to solve.

This is a more numerically stable solution because it removes the need to compute \(\boldsymbol{ \Phi}^\top\boldsymbol{ \Phi}\) as an intermediate. Computing \(\boldsymbol{ \Phi}^\top\boldsymbol{ \Phi}\) is a bad idea because it involves squaring all the elements of \(\boldsymbol{ \Phi}\) and thereby potentially reducing the numerical precision with which we can represent the solution. Operating on \(\boldsymbol{ \Phi}\) directly preserves the numerical precision of the model.

This can be more particularly seen when we begin to work with basis functions in the next session. Some systems that can be resolved with the QR decomposition cannot be resolved by using solve directly.

import scipy as sp

Q, R = np.linalg.qr(Phi)
w = sp.linalg.solve_triangular(R, Q.T@y)
w = pd.DataFrame(w, index=Phi.columns)
w

Non-linear but Linear in the Parameters

One rather nice aspect of our model is that whilst it is non-linear in the inputs, it is still linear in the parameters \(\mathbf{ w}\). This means that our derivations from before continue to operate to allow us to work with this model. In fact, although this is a non-linear regression it is still known as a linear model because it is linear in the parameters,

\[ f(\mathbf{ x}) = \mathbf{ w}^\top \boldsymbol{ \phi}(\mathbf{ x}) \] where the vector \(\mathbf{ x}\) appears inside the basis functions, making our result, \(f(\mathbf{ x})\) non-linear in the inputs, but \(\mathbf{ w}\) appears outside our basis function, making our result linear in the parameters. In practice, our basis function itself may contain its own set of parameters, \[ f(\mathbf{ x}) = \mathbf{ w}^\top \boldsymbol{ \phi}(\mathbf{ x}; \mathbf{ v}), \] that we’ve denoted here as \(\mathbf{ v}\). If these parameters appear inside the basis function then our model is non-linear in these parameters.

Exercise 3

For the following prediction functions state whether the model is linear in the inputs, the parameters or both.

1. \(f(x) = w_1x_1 + w_2\)

2. \(f(x) = w_1\exp(x_1) + w_2x_2 + w_3\)

3. \(f(x) = \log(x_1^{w_1}) + w_2x_2^2 + w_3\)

4. \(f(x) = \exp(-\sum_i(x_i - w_i)^2)\)

5. \(f(x) = \exp(-\mathbf{ w}^\top \mathbf{ x})\)

Fitting the Model Yourself

You now have everything you need to fit a non- linear (in the inputs) basis function model to the marathon data.

Exercise 4

Choose one of the basis functions you have explored above. Compute the design matrix on the covariates (or input data), x. Use the design matrix and the response variable y to solve the following linear system for the model parameters w. \[ \boldsymbol{ \Phi}^\top\boldsymbol{ \Phi}\mathbf{ w}= \boldsymbol{ \Phi}^\top \mathbf{ y} \] Compute the corresponding error on the training data. How does it compare to the error you were able to achieve fitting the basis above? Plot the form of your prediction function from the least squares estimate alongside the form of you prediction function you fitted by hand.

Polynomial Fits to Olympic Marthon Data

import numpy as np
import scipy as sp

Define the polynomial basis function.

import mlai

from mlai import polynomial

Now we include the solution for the linear regression through QR-decomposition.

def basis_fit(Phi, y):
    "Use QR decomposition to fit the basis."""
    Q, R = np.linalg.qr(Phi)
    return sp.linalg.solve_triangular(R, Q.T@y)

Linear Fit

poly_args = {'num_basis':2, # two basis functions (1 and x)
             'data_limits':xlim}
Phi = mlai.polynomial(x, **poly_args)
w = basis_fit(Phi, y)

Now we make some predictions for the fit.

x_pred = np.linspace(xlim[0], xlim[1], 400)[:, np.newaxis]
Phi_pred = mlai.polynomial(x_pred, **poly_args)
f_pred = Phi_pred@w

Figure: Fit of a 1-degree polynomial (a linear model) to the Olympic marathon data.

Cubic Fit

poly_args = {'num_basis':4, # four basis: 1, x, x^2, x^3
             'data_limits':xlim}
Phi = mlai.polynomial(x, **poly_args)
w = basis_fit(Phi, y)

Phi_pred = mlai.polynomial(x_pred, **poly_args)
f_pred = Phi_pred@w

Figure: Fit of a 3-degree polynomial (a cubic model) to the Olympic marathon data.

9th Degree Polynomial Fit

Now we’ll try a 9th degree polynomial fit to the data.

poly_args = {'num_basis':10, # basis up to x^9
             'data_limits':xlim}
Phi = mlai.polynomial(x, **poly_args)
w = basis_fit(Phi, y)

Phi_pred = mlai.polynomial(x_pred, **poly_args)
f_pred = Phi_pred@w

Figure: Fit of a 9-degree polynomial to the Olympic marathon data.

16th Degree Polynomial Fit

Now we’ll try a 16th degree polynomial fit to the data.

poly_args = {'num_basis':17, # basis up to x^16
             'data_limits':xlim}
Phi = mlai.polynomial(x, **poly_args)
w = basis_fit(Phi, y)

Phi_pred = mlai.polynomial(x_pred, **poly_args)
f_pred = Phi_pred@w

Figure: Fit of a 16-degree polynomial to the Olympic marathon data.

28th Degree Polynomial Fit

Now we’ll try a 28th degree polynomial fit to the data.

poly_args = {'num_basis':29, # basis up to x^28
             'data_limits':xlim}
Phi = mlai.polynomial(x, **poly_args)
w = basis_fit(Phi, y)

Phi_pred = mlai.polynomial(x_pred, **poly_args)
f_pred = Phi_pred@w

Figure: Fit of a 28-degree polynomial to the Olympic marathon data.

Polynomial Fits to Olympic Data

import mlai

data_limits=xlim
basis=mlai.Basis(mlai.polynomial, number=1, data_limits=xlim)

Figure: Fit of a 1 degree polynomial to the olympic marathon data.

Figure: Fit of a 2 degree polynomial to the olympic marathon data.

Empirical Risk Minimisation

Expected Loss

Our objective function so far has been the negative log likelihood, which we have minimized (via the sum of squares error) to obtain our model. However, there is an alternative perspective on an objective function, that of a loss function. A loss function is a cost function associated with the penalty you might need to pay for a particular incorrect decision. One approach to machine learning involves specifying a loss function and considering how much a particular model is likely to cost us across its lifetime. We can represent this with an expectation. If our loss function is given as \(L(y, x, \mathbf{ w})\) for a particular model that predicts \(y\) given \(x\) and \(\mathbf{ w}\) then we are interested in minimizing the expected loss under the likely distribution of \(y\) and \(x\). To understand this formally we define the true distribution of the data samples, \(y\), \(x\). This is a particular distribution that we don’t typically have access to. To represent it we define a variant of the letter ‘P,’ \(\mathbb{P}(y, x)\). If we genuinely pay \(L(y, x, \mathbf{ w})\) for every mistake we make, and the future test data is genuinely drawn from \(\mathbb{P}(y, x)\) then we can define our expected loss, or risk, to be, \[ R(\mathbf{ w}) = \int L(y, x, \mathbf{ w}) \mathbb{P}(y, x) \text{d}y \text{d}x. \] Of course, in practice, this value can’t be computed but it serves as a reminder of what it is we are aiming to minimise and under certain circumstances it can be approximated.

Here we have used \(L(\cdot)\) as our notation for the loss function. The cost we expect to pay for making errors. This is a different interpretation of the objective function, \(E(\cdot)\), fromt he idea of negative log likelihood we see in Gauss’s probabilistic approach.

Sample-Based Approximations

A sample-based approximation to an expectation involves replacing the true expectation with a sum over samples from the distribution. \[ \int f(z) p(z) \text{d}z\approx \frac{1}{s}\sum_{i=1}^s f(z_i). \] if \(\{z_i\}_{i=1}^s\) are a set of \(s\) independent and identically distributed samples from the distribution \(p(z)\). This approximation becomes better for larger \(s\), although the rate of convergence to the true integral will be very dependent on the distribution \(p(z)\) and the function \(f(z)\).

That said, this means we can approximate our true integral with the sum, \[ R(\mathbf{ w}) \approx \frac{1}{n}\sum_{i=1}^{n} L(y_i, x_i, \mathbf{ w}). \]

if \(y_i\) and \(x_i\) are independent samples from the true distribution \(\mathbb{P}(y, x)\). Minimizing this sum directly is known as empirical risk minimization. The sum of squares error we have been using can be recovered for this case by considering a squared loss, \[ L(y, x, \mathbf{ w}) = (y-\mathbf{ w}^\top\boldsymbol{\phi}(x))^2, \] which gives an empirical risk of the form \[ R(\mathbf{ w}) \approx \frac{1}{n} \sum_{i=1}^{n} (y_i - \mathbf{ w}^\top \boldsymbol{\phi}(x_i))^2 \] which up to the constant \(\frac{1}{n}\) is identical to the objective function we have been using so far.

Estimating Risk through Validation

Unfortuantely, minimising the empirial risk only guarantees something about our performance on the training data. If we don’t have enough data for the approximation to the risk to be valid, then we can end up performing significantly worse on test data. Fortunately, we can also estimate the risk for test data through estimating the risk for unseen data. The main trick here is to ‘hold out’ a portion of our data from training and use the models performance on that sub-set of the data as a proxy for the true risk. This data is known as ‘validation’ data. It contrasts with test data, because its values are known at the model design time. However, in contrast to test date we don’t use it to fit our model. This means that it doesn’t exhibit the same bias that the empirical risk does when estimating the true risk.

Validation

Next we will explore techniques for model selection that make use of validation data. Data that isn’t seen by the model in the learning (or fitting) phase, but is used to validate our choice of model from amoungst the different designs we have selected.

In machine learning, we are looking to minimise the value of our objective function \(E\) with respect to its parameters \(\mathbf{ w}\). We do this by considering our training data. We minimize the value of the objective function as it’s observed at each training point. However we are really interested in how the model will perform on future data. For evaluating that we choose to hold out a portion of the data for evaluating the quality of the model.

We will review the different methods of model selection on the Olympics marathon data.

Validation on the Olympic Marathon Data

The first thing we’ll do is fit a standard linear model to the data. We recall from previous lectures and lab classes that to do this we need to solve the system \[ \boldsymbol{ \Phi}^\top \boldsymbol{ \Phi}\mathbf{ w}= \boldsymbol{ \Phi}^\top \mathbf{ y} \] for \(\mathbf{ w}\) and use the resulting vector to make predictions at the training points and test points, \[ \mathbf{ f}= \boldsymbol{ \Phi}\mathbf{ w}. \] The prediction function can be used to compute the objective function, \[ E(\mathbf{ w}) = \sum_{i}^{n} (y_i - \mathbf{ w}^\top\phi(\mathbf{ y}_i))^2 \] by substituting in the prediction in vector form we have \[ E(\mathbf{ w}) = (\mathbf{ y}- \mathbf{ f})^\top(\mathbf{ y}- \mathbf{ f}) \]

Exercise 5

In this question you will construct some flexible general code for fitting linear models.

Create a python function that computes \(\boldsymbol{ \Phi}\) for the linear basis, \[\boldsymbol{ \Phi}= \begin{bmatrix} \mathbf{ y}& \mathbf{1}\end{bmatrix}\] Name your function linear. Phi should be in the form of a design matrix and x should be in the form of a numpy two dimensional array with \(n\) rows and 1 column Calls to your function should be in the following form:

Phi = linear(x)

Create a python function that accepts, as arguments, a python function that defines a basis (like the one you’ve just created called linear) as well as a set of inputs and a vector of parameters. Your new python function should return a prediction. Name your function prediction. The return value f should be a two dimensional numpy array with \(n\) rows and \(1\) column, where \(n\) is the number of data points. Calls to your function should be in the following form:

f = prediction(w, x, linear)

Create a python function that computes the sum of squares objective function (or error function). It should accept your input data (or covariates) and target data (or response variables) and your parameter vector w as arguments. It should also accept a python function that represents the basis. Calls to your function should be in the following form:

e = objective(w, x, y, linear)

Create a function that solves the linear system for the set of parameters that minimizes the sum of squares objective. It should accept input data, target data and a python function for the basis as the inputs. Calls to your function should be in the following form:

w = fit(x, y, linear)

Fit a linear model to the olympic data using these functions and plot the resulting prediction between 1890 and 2020. Set the title of the plot to be the error of the fit on the training data.

Polynomial Fit: Training Error

Exercise 6

In this question we extend the code above to a non- linear basis (a quadratic function).

Start by creating a python-function called quadratic. It should compute the quadratic basis. \[ \boldsymbol{ \Phi}= \begin{bmatrix} \mathbf{1} & \mathbf{ y}& \mathbf{ y}^2\end{bmatrix} \] It should be called in the following form:

Phi = quadratic(x)

Use this to compute the quadratic fit for the model, again plotting the result titled by the error.

Polynomial Fits to Olympics Data

Figure: Polynomial fit to olympic data with 28 basis functions.

Hold Out Validation on Olympic Marathon Data

Figure: Olympic marathon data with validation error for extrapolation.

Extrapolation

Interpolation

Figure: Olympic marathon data with validation error for interpolation.

Choice of Validation Set

Hold Out Data

You have a conclusion as to which model fits best under the training error, but how do the two models perform in terms of validation? In this section we consider hold out validation. In hold out validation we remove a portion of the training data for validating the model on. The remaining data is used for fitting the model (training). Because this is a time series prediction, it makes sense for us to hold out data at the end of the time series. This means that we are validating on future predictions. We will hold out data from after 1980 and fit the model to the data before 1980.

# select indices of data to 'hold out'
indices_hold_out = np.flatnonzero(x>1980)

# Create a training set
x_train = np.delete(x, indices_hold_out, axis=0)
y_train = np.delete(y, indices_hold_out, axis=0)

# Create a hold out set
x_valid = np.take(x, indices_hold_out, axis=0)
y_valid = np.take(y, indices_hold_out, axis=0)

Exercise 7

For both the linear and quadratic models, fit the model to the data up until 1980 and then compute the error on the held out data (from 1980 onwards). Which model performs better on the validation data?

Richer Basis Set

Now we have an approach for deciding which model to retain, we can consider the entire family of polynomial bases, with arbitrary degrees.

Exercise 8

Now we are going to build a more sophisticated form of basis function, one that can accept arguments to its inputs (similar to those we used in this lab). Here we will start with a polynomial basis.

def polynomial(x, degree, loc, scale):
    degrees =np.arange(degree+1)
    return ((x-loc)/scale)**degrees

The basis as we’ve defined it has three arguments as well as the input. The degree of the polynomial, the scale of the polynomial and the offset. These arguments need to be passed to the basis functions whenever they are called. Modify your code to pass these additional arguments to the python function for creating the basis. Do this for each of your functions predict, fit and objective. You will find *args (or **kwargs) useful.

Write code that tries to fit different models to the data with polynomial basis. Use a maximum degree for your basis from 0 to 17. For each polynomial store the hold out validation error and the training error. When you have finished the computation plot the hold out error for your models and the training error for your p. When computing your polynomial basis use offset=1956. and scale=120. to ensure that the data is mapped (roughly) to the -1, 1 range.

Which polynomial has the minimum training error? Which polynomial has the minimum validation error?

Leave One Out Validation

Hold out validation uses a portion of the data to hold out and a portion of the data to train on. There is always a compromise between how much data to hold out and how much data to train on. The more data you hold out, the better the estimate of your performance at ‘run-time’ (when the model is used to make predictions in real applications). However, by holding out more data, you leave less data to train on, so you have a better validation, but a poorer quality model fit than you could have had if you’d used all the data for training. Leave one out cross validation leaves as much data in the training phase as possible: you only take one point out for your validation set. However, if you do this for hold-out validation, then the quality of your validation error is very poor because you are testing the model quality on one point only. In cross validation the approach is to improve this estimate by doing more than one model fit. In leave one out cross validation you fit \(n\) different models, where \(n\) is the number of your data. For each model fit you take out one data point, and train the model on the remaining \(n-1\) data points. You validate the model on the data point you’ve held out, but you do this \(n\) times, once for each different model. You then take the average of all the \(n\) badly estimated hold out validation errors. The average of this estimate is a good estimate of performance of those models on the test data.

Exercise 9

Write code that computes the leave one out validation error for the olympic data and the polynomial basis. Use the functions you have created above: objective, fit, polynomial. Compute the leave-one-out cross validation error for basis functions containing a maximum degree from 0 to 17.

\(k\)-fold Cross Validation

Leave one out cross validation produces a very good estimate of the performance at test time, and is particularly useful if you don’t have a lot of data. In these cases you need to make as much use of your data for model fitting as possible, and having a large hold out data set (to validate model performance) can have a significant effect on the size of the data set you have to fit your model, and correspondingly, the complexity of the model you can fit. However, leave one out cross validation involves fitting \(n\) models, where \(n\) is your number of training data. For the olympics example, this is only 27 model fits, but in practice many data sets consist thousands or millions of data points, and fitting many millions of models for estimating validation error isn’t really practical. One option is to return to hold out validation, but another approach is to perform \(k\)-fold cross validation. In \(k\)-fold cross validation you split your data into \(k\) parts. Then you use \(k-1\) of those parts for training, and hold out one part for validation. Just like we did for the hold out validation above. In cross validation, however, you repeat this process. You swap the part of the data you just used for validation back in to the training set and select another part for validation. You then fit the model to the new training data and validate on the portion of data you’ve just extracted. Each split of training/validation data is called a fold and since you do this process \(k\) times, the procedure is known as \(k\)-fold cross validation. The term cross refers to the fact that you cross over your validation portion back into the training data every time you perform a fold.

Exercise 10

Perform \(k\)-fold cross validation on the olympic data with your polynomial basis. Use \(k\) set to 5 (e.g. five fold cross validation). Do the different forms of validation select different models? Does five fold cross validation always select the same model?

Note: The data doesn’t divide into 5 equal size partitions for the five fold cross validation error. Don’t worry about this too much. Two of the partitions will have an extra data point. You might find np.random.permutation? useful.

Notice how as we vary the “part” of the cross validation, the fit varies. This variation is greater for high degree polynomials than for small degree polynomials like linear and quadratic models. This variation is coming from different variations of the data set.

An explicit approach to assessing this variations is to use “bootstrap sampling.”

The Bootstrap

Bootstrap sampling (Efron, 1979) is an approach to assessing the sensitivity of the model to different variations on a data set. In an ideal world, we’d like to be able to look at different realisations from the original data generating distribution \(\mathbb{P}(y, \mathbf{ x})\), but this is not available to us.

In bootstrap sampling, we take the sample we have, \[ \mathbf{ y}, \mathbf{X}\sim \mathbb{P}(y, \mathbf{ x}) \] and resample from that data, rather than from the true distribution. So, we have a new data set, \(\hat{\mathbf{ y}}\), \(\hat{\mathbf{X}}\) which is sampled from the original with replacement.

import numpy as np

def bootstrap(X):
    "Return a bootstrap sample from a data set."
    n = X.shape[0]
    ind = np.random.choice(n, n, replace=True) # Sample randomly with replacement.
    return X[ind, :]

Bootstrap and Olympic Marathon Data

First we define a function to bootstrap resample our dataset.

import numpy as np

def bootstrap(X, y):
    "Return a bootstrap sample from a data set."
    n = X.shape[0]
    ind = np.random.choice(n, n, replace=True) # Sample randomly with replacement.
    return X[ind, :], y[ind, :]

num_bootstraps = 10

def bootstrap_fit(Phi, y, size):
    W = np.zeros((Phi.shape[1], size))
    for i in range(size):
        Phi_hat, y_hat = bootstrap(Phi, y)
        W[:, i:i+1] = basis_fit(Phi_hat, y_hat)
    return W

Linear Fit

poly_args = {'num_basis':2, # two basis functions (1 and x)
             'data_limits':xlim}
Phi = mlai.polynomial(x, **poly_args)
W_hat = bootstrap_fit(Phi, y, num_bootstraps)

Now we make some predictions for the fit.

x_pred = np.linspace(xlim[0], xlim[1], 400)[:, np.newaxis]
Phi_pred = mlai.polynomial(x_pred, **poly_args)
f_pred = Phi_pred@W_hat

Figure: Fit of a 1 degree polynomial (a linear model) to the olympic marathon data.

Cubic Fit

poly_args = {'num_basis':4, # four basis: 1, x, x^2, x^3
             'data_limits':xlim}
Phi = mlai.polynomial(x, **poly_args)
W_hat = bootstrap_fit(Phi, y, num_bootstraps)

Phi_pred = mlai.polynomial(x_pred, **poly_args)
f_pred = Phi_pred@W_hat

Figure: Fit of a 3 degree polynomial (a cubic model) to the olympic marathon data.

9th Degree Polynomial Fit

Now we’ll try a 9th degree polynomial fit to the data.

poly_args = {'num_basis':10, # basis up to x^9
             'data_limits':xlim}
Phi = mlai.polynomial(x, **poly_args)
W_hat = bootstrap_fit(Phi, y, num_bootstraps)

Phi_pred = mlai.polynomial(x_pred, **poly_args)
f_pred = Phi_pred@W_hat

Figure: Fit of a 9 degree polynomial to the olympic marathon data.

16th Degree Polynomial Fit

Now we’ll try a 16th degree polynomial fit to the data.

poly_args = {'num_basis':17, # basis up to x^16
             'data_limits':xlim}
Phi = mlai.polynomial(x, **poly_args)
W_hat = bootstrap_fit(Phi, y, num_bootstraps)

Phi_pred = mlai.polynomial(x_pred, **poly_args)
f_pred = Phi_pred@W_hat

Figure: Fit of a 16 degree polynomial to the olympic marathon data.

Bootstrap Confidence Intervals

We can also use the bootstrap to create confidence intervals for our predictions, showing the uncertainty in our model.

def plot_polynomial_bootstrap_confidence(x, y, x_pred, degree=3, num_bootstraps=50):
    """Plot bootstrap confidence intervals for polynomial fit.

    :param x: training inputs
    :param y: training outputs
    :param x_pred: prediction points
    :param degree: polynomial degree
    :param num_bootstraps: number of bootstrap samples
    """
    poly_args = {'num_basis': degree + 1, 'data_limits': xlim}
    Phi = mlai.polynomial(x, **poly_args)
    W_hat = bootstrap_fit(Phi, y, num_bootstraps)

    Phi_pred = mlai.polynomial(x_pred, **poly_args)
    f_pred_bootstrap = Phi_pred @ W_hat  # Shape: (n_pred_points, n_bootstrap_samples)

    # Transpose to get shape (n_bootstrap_samples, n_pred_points)
    f_pred_bootstrap = f_pred_bootstrap.T

    # Compute confidence intervals
    f_mean = np.mean(f_pred_bootstrap, axis=0)  # Mean across bootstrap samples
    f_std = np.std(f_pred_bootstrap, axis=0)    # Std across bootstrap samples

    # Ensure all arrays have the right shape
    if f_mean.ndim > 1:
        f_mean = f_mean.flatten()
    if f_std.ndim > 1:
        f_std = f_std.flatten()

    f_lower = f_mean - 1.96 * f_std  # 95% confidence interval
    f_upper = f_mean + 1.96 * f_std

    return f_mean, f_lower, f_upper, f_pred_bootstrap

f_mean, f_lower, f_upper, f_pred_bootstrap = plot_polynomial_bootstrap_confidence(x, y, x_pred, degree=3)

Figure: Bootstrap confidence intervals for a cubic polynomial fit to Olympic marathon data. The shaded region shows the 95% confidence interval, and individual bootstrap fits are shown in light green.

The confidence intervals show the uncertainty in our predictions. The width of the confidence interval reflects the variance of the model - wider intervals indicate higher variance. This visualization helps us understand not just the point predictions but also the reliability of those predictions.

The bootstrap method provides a powerful way to estimate bias and variance without needing to know the true underlying function. By resampling from our training data, we can approximate how our model would perform on different samples from the same distribution, giving us insights into the bias-variance tradeoff.

This analysis is particularly valuable for model selection - we can choose the polynomial degree that minimizes the total error (bias + variance) rather than just the training error.

Bias Variance Decomposition

One of Breiman’s ideas for improving predictive performance is known as bagging (Breiman, 1996). The idea is to train a number of models on the data such that they overfit (high variance). Then average the predictions of these models. The models are trained on different bootstrap samples (Efron, 1979) and their predictions are aggregated giving us the acronym, Bagging. By combining decision trees with bagging, we recover random forests (Breiman, 2001).

Bias and variance can also be estimated through Efron’s bootstrap (Efron, 1979), and the traditional view has been that there’s a form of Goldilocks effect, where the best predictions are given by the model that is ‘just right’ for the amount of data available. Not to simple, not too complex. The idea is that bias decreases with increasing model complexity and variance increases with increasing model complexity. Typically plots begin with the Mummy bear on the left (too much bias) end with the Daddy bear on the right (too much variance) and show a dip in the middle where the Baby bear (just) right finds themselves.

The Daddy bear is typically positioned at the point where the model can exactly interpolate the data. For a generalized linear model (McCullagh and Nelder, 1989), this is the point at which the number of parameters is equal to the number of data¹.

The bias-variance decomposition (Geman et al., 1992) considers the expected test error for different variations of the training data sampled from, \(\mathbb{P}(\mathbf{ x}, y)\) \[\begin{align*} R(\mathbf{ w}) = & \int \left(y- f^*(\mathbf{ x})\right)^2 \mathbb{P}(y, \mathbf{ x}) \text{d}y\text{d}\mathbf{ x}\\ & \triangleq \mathbb{E}\left[ \left(y- f^*(\mathbf{ x})\right)^2 \right]. \end{align*}\]

This can be decomposed into two parts, \[ \begin{align*} \mathbb{E}\left[ \left(y- f(\mathbf{ x})\right)^2 \right] = & \text{bias}\left[f^*(\mathbf{ x})\right]^2 + \text{variance}\left[f^*(\mathbf{ x})\right] +\sigma^2, \end{align*} \] where the bias is given by \[ \text{bias}\left[f^*(\mathbf{ x})\right] = \mathbb{E}\left[f^*(\mathbf{ x})\right] - f(\mathbf{ x}) \] and it summarizes error that arises from the model’s inability to represent the underlying complexity of the data. For example, if we were to model the marathon pace of the winning runner from the Olympics by computing the average pace across time, then that model would exhibit bias error because the reality of Olympic marathon pace is it is changing (typically getting faster).

The variance term is given by \[ \text{variance}\left[f^*(\mathbf{ x})\right] = \mathbb{E}\left[\left(f^*(\mathbf{ x}) - \mathbb{E}\left[f^*(\mathbf{ x})\right]\right)^2\right]. \] The variance term is often described as arising from a model that is too complex, but we must be careful with this idea. Is the model really too complex relative to the real world that generates the data? The real world is a complex place, and it is rare that we are constructing mathematical models that are more complex than the world around us. Rather, the ‘too complex’ refers to ability to estimate the parameters of the model given the data we have. Slight variations in the training set cause changes in prediction.

Models that exhibit high variance are sometimes said to ‘overfit’ the data whereas models that exhibit high bias are sometimes described as ‘underfitting’ the data.

We can also use the bootstrap to characterise the bias and variance area for different polynomials on the olympic data.

Bias-Variance Analysis for Olympic Marathon Data

We can use the bootstrap to characterise the bias and variance for different polynomials on the olympic data. The bootstrap allows us to estimate how much the model predictions vary when trained on different samples from the same underlying distribution.

For each polynomial degree, we compute the bias and variance by comparing the bootstrap predictions at the training inputs against the observed targets. Concretely, we average the bootstrap predictions per training input and measure squared error to the observed \(y\) (bias\(^2\)), and we average the bootstrap prediction variance across training inputs (variance). This non-OOB bootstrap estimate exhibits the expected pattern: high bias for low-degree polynomials and higher variance for high-degree polynomials.

import numpy as np
import matplotlib.pyplot as plt
import mlai.plot as plot
import mlai

def compute_bias_variance(x_pred, f_pred_bootstrap, f_full_dataset):
    """Compute bias and variance from bootstrap predictions.

    :param x_pred: prediction points
    :param f_pred_bootstrap: bootstrap predictions (n_bootstrap, n_points)
    :param f_full_dataset: prediction from full dataset
    """
    # Mean prediction across bootstrap samples
    f_mean = np.mean(f_pred_bootstrap, axis=0)

    # Ensure f_mean has the right shape (flatten if needed)
    if f_mean.ndim > 1:
        f_mean = f_mean.flatten()
    if f_full_dataset.ndim > 1:
        f_full_dataset = f_full_dataset.flatten()

    # Bias: difference between mean bootstrap prediction and full dataset prediction
    bias = np.mean((f_mean - f_full_dataset)**2)

    # Variance: average variance of bootstrap predictions around their mean
    variance = np.mean(np.var(f_pred_bootstrap, axis=0))

    return bias, variance, f_mean

def analyze_polynomial_bias_variance(x, y, x_pred, max_degree=6, num_bootstraps=50):
    """Analyze bias-variance tradeoff for polynomial models.

    :param x: training inputs
    :param y: training outputs
    :param x_pred: prediction points
    :param max_degree: maximum polynomial degree to test
    :param num_bootstraps: number of bootstrap samples
    """
    degrees = range(1, max_degree + 1)
    biases = []
    variances = []
    total_errors = []

    for degree in degrees:
        # Bootstrap predictions for this degree
        poly_args = {'num_basis': degree + 1, 'data_limits': xlim}
        Phi = mlai.polynomial(x, **poly_args)
        W_hat = bootstrap_fit(Phi, y, num_bootstraps)

        # Predictions at training inputs for each bootstrap model
        # Phi: (n_train, n_basis), W_hat: (n_basis, B) -> (n_train, B)
        F_train = (Phi @ W_hat).T  # (B, n_train)

        # Per-point bootstrap mean and variance of predictions
        mu = F_train.mean(axis=0)            # (n_train,)
        var_point = F_train.var(axis=0)      # (n_train,)

        # Bias^2 and Variance using observed targets as reference
        bias = np.mean((mu - y.flatten())**2)
        variance = np.mean(var_point)

        biases.append(bias)
        variances.append(variance)
        total_errors.append(bias + variance)

    return degrees, biases, variances, total_errors

degrees, biases, variances, total_errors = analyze_polynomial_bias_variance(x, y, x_pred)

Figure: Bias-variance tradeoff for polynomial models on Olympic marathon data. The bias decreases with model complexity while variance increases. The optimal model balances these two sources of error.

The plot shows the classic bias-variance tradeoff. As we increase the polynomial degree:

1. Bias decreases: Higher degree polynomials can capture more complex patterns in the data
2. Variance increases: Higher degree polynomials are more sensitive to variations in the training data
3. Total error: The sum of bias and variance shows a U-shaped curve with an optimal point

The optimal polynomial degree (around 3-4 in this case) minimizes the total generalization error by balancing bias and variance.

This analysis demonstrates the “Goldilocks principle” in machine learning - we want a model that’s not too simple (high bias) and not too complex (high variance), but just right for the amount of data we have.

No Free Lunch Theorem

Also related on generalisation error is the so called ‘no free lunch theorem,’ which refers to our inability to decide what a better learning algorithm is without making assumptions about the data (Wolpert, 1996) (see also Wolpert (2002)).

NFL results show that without constraints on the data-generating distribution, no learning algorithm outperforms another in expectation. Any advantage derives from aligning the learner’s inductive bias with the structure present in the data.

We’ve seen how model complexity trades bias for variance and how resampling quantifies variability. NFL explains why there is no globally optimal choice: effective generalisation requires assumptions tailored to the task (basis choice, degree, smoothness, priors).

Regularisation

The solution to the linear system is given by solving, \[ \boldsymbol{ \Phi}^\top\boldsymbol{ \Phi}\mathbf{ w}= \boldsymbol{ \Phi}^\top\mathbf{ y} \] for \(\mathbf{ w}\).

But if \(\boldsymbol{ \Phi}^\top\boldsymbol{ \Phi}\) is not full rank, this system cannot be solved. This is reflective of an underdetermined system of equations. There are infinite solutions. This happens when there are more basis functions than data points, in effect the number of data we have is not enough to determine the parameters.

Thinking about this in terms of the Hessian, if \(\boldsymbol{ \Phi}^\top\boldsymbol{ \Phi}\) is not full rank, then we are no longer at a minimum. We are in a trough, because not full rank implies that there are fewer eigenvectors than dimensions, in effect for those dimensions where there is no eigenvector, the objective function is ‘flat.’ It is ambivalent to changes in parameters. This implies there are infinite valid solutions.

One solution to this problem is to regularise the system.

Coefficient Shrinkage

Coefficient shrinkage is a technique where the parameters of the of the model are ‘encouraged’ to be small. In practice this is normally done by augmenting the objective function with a term that keeps the parameters low, typically by penalizing a norm.

Tikhonov Regularisation

In neural network models this approach is sometimes called ‘weight decay.’ At every gradient step we reduce the value of the weight a little. This idea comes from an approach called Tikhonov regularization (Tikhonov and Arsenin, 1977), where the objective function is augmented by the L2 norm of the weights, \[ L(\mathbf{ w}) = (\mathbf{ y}- \mathbf{ f})^\top(\mathbf{ y}- \mathbf{ f}) + \alpha\left\Vert \mathbf{W} \right\Vert_2^2 \] with some weighting \(\alpha >0\). This has the effect of changing the Hessian at the minimum to \[ \boldsymbol{ \Phi}^\top\boldsymbol{ \Phi}+ \alpha \mathbf{I} \] Which is always full rank. The minimal eigenvalues are now given by \(\alpha\).

Lasso

Other techniques for regularization based on a norm of the parameters include the Lasso (Tibshirani, 1996), which is an L1 norm of the parameters

Splines, Functions, Hilbert Kernels

Regularisation of the parameters has the desired effect of making the solution viable, but it can sometimes be difficult to interpret, particularly if the parameters don’t have any inherent meaning (like in a neural network). An alternative approach is to regularize the function, \(\mathbf{ f}\), directly, (see e.g., Kimeldorf and Wahba (1970) and Wahba (1990)). This is the approach taken by spline models which use energy-based regularisation for \(f(\cdot)\) and also kernel methods such as the support vector machine (Schölkopf and Smola, 2001).

Training with Noise

In practice, and across the last two waves of neural networks, other techniques for regularization have been used which can be seen as perturbing the neural network in some way. For example, in dropout (Srivastava et al., 2014), different basis functions are eliminated from the gradient computation at each gradient update.

Many of these perturbations have some form of regularizing effect. The exact nature of the effect is not always easy to characterize, but in some cases, we can assess how these manipulations effect the model. For example, Bishop (1995) analyzed training with ‘noisy inputs’ and showed conditions under which it’s equivalent to Tikhonov regularization.

But in general, these approaches can have different interpretations and they’ve also been related to ensemble learning (e.g. related to bagging or Bayesian approaches).

Thanks!

For more information on these subjects and more you might want to check the following resources.

• company: Trent AI
• book: The Atomic Human
• twitter: @lawrennd
• podcast: The Talking Machines
• newspaper: Guardian Profile Page
• blog: http://inverseprobability.com

References
