Post-Digital Transformation: Intellectual Debt

Week : Post-Digital Transformation: Intellectual Debt

[Powerpoint]

Abstract:

The Great AI Fallacy

[edit]

There is a lot of variation in the use of the term artificial intelligence. I’m sometimes asked to define it, but depending on whether you’re speaking to a member of the public, a fellow machine learning researcher, or someone from the business community, the sense of the term differs.

However, underlying its use I’ve detected one disturbing trend. A trend I’m beginining to think of as “The Great AI Fallacy”.

The fallacy is associated with an implicit promise that is embedded in many statements about Artificial Intelligence. Artificial Intelligence, as it currently exists, is merely a form of automated decision making. The implicit promise of Artificial Intelligence is that it will be the first wave of automation where the machine adapts to the human, rather than the human adapting to the machine.

How else can we explain the suspension of sensible business judgment that is accompanying the hype surrounding AI?

This fallacy is particularly pernicious because there are serious benefits to society in deploying this new wave of data-driven automated decision making. But the AI Fallacy is causing us to suspend our calibrated skepticism that is needed to deploy these systems safely and efficiently.

The problem is compounded because many of the techniques that we’re speaking of were originally developed in academic laboratories in isolation from real-world deployment.

Figure: We seem to have fallen for a perspective on AI that suggests it will adapt to our schedule, rather in the manner of a 1930s manservant.

Artificial vs Natural Systems

[edit]

Let’s take a step back from artificial intelligence, and consider natural intelligence. Or even more generally, let’s consider the contrast between an artificial system and an natural system. The key difference between the two is that artificial systems are designed whereas natural systems are evolved.

Systems design is a major component of all Engineering disciplines. The details differ, but there is a single common theme: achieve your objective with the minimal use of resources to do the job. That provides efficiency. The engineering designer imagines a solution that requires the minimal set of components to achieve the result. A water pump has one route through the pump. That minimises the number of components needed. Redundancy is introduced only in safety critical systems, such as aircraft control systems. Students of biology, however, will be aware that in nature system-redundancy is everywhere. Redundancy leads to robustness. For an organism to survive in an evolving environment it must first be robust, then it can consider how to be efficient. Indeed, organisms that evolve to be too efficient at a particular task, like those that occupy a niche environment, are particularly vulnerable to extinction.

This notion is akin to the idea that only the best will survive, popularly encoded into an notion of evolution by Herbert Spencer’s quote.

Survival of the fittest

Herbet Spencer, 1864

Darwin himself never said “Survival of the Fittest” he talked about evolution by natural selection.

Non-survival of the non-fit

Evolution is better described as “non-survival of the non-fit”. You don’t have to be the fittest to survive, you just need to avoid the pitfalls of life. This is the first priority.

So it is with natural vs artificial intelligences. Any natural intelligence that was not robust to changes in its external environment would not survive, and therefore not reproduce. In contrast the artificial intelligences we produce are designed to be efficient at one specific task: control, computation, playing chess. They are fragile.

The first rule of a natural system is not be intelligent, it is “don’t be stupid”.

A mistake we make in the design of our systems is to equate fitness with the objective function, and to assume it is known and static. In practice, a real environment would have an evolving fitness function which would be unknown at any given time.

You can also read this blog post on Natural and Artificial Intelligence..

The first criterion of a natural intelligence is don’t fail, not because it has a will or intent of its own, but because if it had failed it wouldn’t have stood the test of time. It would no longer exist. In contrast, the mantra for artificial systems is to be more efficient. Our artificial systems are often given a single objective (in machine learning it is encoded in a mathematical function) and they aim to achieve that objective efficiently. These are different characteristics. Even if we wanted to incorporate don’t fail in some form, it is difficult to design for. To design for “don’t fail”, you have to consider every which way in which things can go wrong, if you miss one you fail. These cases are sometimes called corner cases. But in a real, uncontrolled environment, almost everything is a corner. It is difficult to imagine everything that can happen. This is why most of our automated systems operate in controlled environments, for example in a factory, or on a set of rails. Deploying automated systems in an uncontrolled environment requires a different approach to systems design. One that accounts for uncertainty in the environment and is robust to unforeseen circumstances.

Today’s Artificial Systems

The systems we produce today only work well when their tasks are pigeonholed, bounded in their scope. To achieve robust artificial intelligences we need new approaches to both the design of the individual components, and the combination of components within our AI systems. We need to deal with uncertainty and increase robustness. Today, it is easy to make a fool of an artificial intelligent agent, technology needs to address the challenge of the uncertain environment to achieve robust intelligences.

However, even if we find technological solutions for these challenges, it may be that the essence of human intelligence remains out of reach. It may be that the most quintessential element of our intelligence is defined by limitations. Limitations that computers have never experienced.

Claude Shannon developed the idea of information theory: the mathematics of information. He defined the amount of information we gain when we learn the result of a coin toss as a “bit” of information. A typical computer can communicate with another computer with a billion bits of information per second. Equivalent to a billion coin tosses per second. So how does this compare to us? Well, we can also estimate the amount of information in the English language. Shannon estimated that the average English word contains around 12 bits of information, twelve coin tosses, this means our verbal communication rates are only around the order of tens to hundreds of bits per second. Computers communicate tens of millions of times faster than us, in relative terms we are constrained to a bit of pocket money, while computers are corporate billionaires.

Our intelligence is not an island, it interacts, it infers the goals or intent of others, it predicts our own actions and how we will respond to others. We are social animals, and together we form a communal intelligence that characterises our species. For intelligence to be communal, our ideas to be shared somehow. We need to overcome this bandwidth limitation. The ability to share and collaborate, despite such constrained ability to communicate, characterises us. We must intellectually commune with one another. We cannot communicate all of what we saw, or the details of how we are about to react. Instead, we need a shared understanding. One that allows us to infer each other’s intent through context and a common sense of humanity. This characteristic is so strong that we anthropomorphise any object with which we interact. We apply moods to our cars, our cats, our environment. We seed the weather, volcanoes, trees with intent. Our desire to communicate renders us intellectually animist.

But our limited bandwidth doesn’t constrain us in our imaginations. Our consciousness, our sense of self, allows us to play out different scenarios. To internally observe how our self interacts with others. To learn from an internal simulation of the wider world. Empathy allows us to understand others’ likely responses without having the full detail of their mental state. We can infer their perspective. Self-awareness also allows us to understand our own likely future responses, to look forward in time, play out a scenario. Our brains contain a sense of self and a sense of others. Because our communication cannot be complete it is both contextual and cultural. When driving a car in the UK a flash of the lights at a junction concedes the right of way and invites another road user to proceed, whereas in Italy, the same flash asserts the right of way and warns another road user to remain.

Our main intelligence is our social intelligence, intelligence that is dedicated to overcoming our bandwidth limitation. We are individually complex, but as a society we rely on shared behaviours and oversimplification of our selves to remain coherent.

This nugget of our intelligence seems impossible for a computer to recreate directly, because it is a consequence of our evolutionary history. The computer, on the other hand, was born into a world of data, of high bandwidth communication. It was not there through the genesis of our minds and the cognitive compromises we made are lost to time. To be a truly human intelligence you need to have shared that journey with us.

Of course, none of this prevents us emulating those aspects of human intelligence that we observe in humans. We can form those emulations based on data. But even if an artificial intelligence can emulate humans to a high degree of accuracy it is a different type of intelligence. It is not constrained in the way human intelligence is. You may ask does it matter? Well, it is certainly important to us in many domains that there’s a human pulling the strings. Even in pure commerce it matters: the narrative story behind a product is often as important as the product itself. Handmade goods attract a price premium over factory made. Or alternatively in entertainment: people pay more to go to a live concert than for streaming music over the internet. People will also pay more to go to see a play in the theatre rather than a movie in the cinema.

In many respects I object to the use of the term Artificial Intelligence. It is poorly defined and means different things to different people. But there is one way in which the term is very accurate. The term artificial is appropriate in the same way we can describe a plastic plant as an artificial plant. It is often difficult to pick out from afar whether a plant is artificial or not. A plastic plant can fulfil many of the functions of a natural plant, and plastic plants are more convenient. But they can never replace natural plants.

In the same way, our natural intelligence is an evolved thing of beauty, a consequence of our limitations. Limitations which don’t apply to artificial intelligences and can only be emulated through artificial means. Our natural intelligence, just like our natural landscapes, should be treasured and can never be fully replaced.

The Mythical Man-month

[edit]

Figure: The Mythical Man-month (Brooks, n.d.) is a 1975 book focussed on the challenges of software project coordination.

However, when managing systems in production, you soon discover maintenance of a rapidly deployed system is not your only problem.

To deploy large and complex software systems, an engineering approach known as “separation of concerns” is taken. Frederick Brooks’ book “The Mythical Man-month” (Brooks, n.d.), has itself gained almost mythical status in the community. It focuses on what has become known as Brooks’ law “adding manpower to a late software project makes it later”.

Adding people (men or women!) to a project delays it because of the communication overhead required to get people up to speed.

Technical Consequence

[edit]

Classical systems design assumes that the system is decomposable. That we can decompose the complex decision making process into distinct and independently designable parts. The composition of these parts gives us our final system.

Nicolas Negroponte, the original founder of MIT’s media lab used to write a column called ‘bits and atoms’. This referred to the ability of information to effect movement of goods in the physical world. It is this interaction where machine learning technologies have the possibility to bring most benefit.

Figure: Some software components in a ride allocation system. Circled components are hypothetical, rectangles represent actual data.

Machine Learning Systems Design

[edit]

The challenges of integrating different machine learning components into a whole that acts effectively as a system seem unresolved. In software engineering, separating parts of a system in this way is known as component-based software engineering. The core idea is that the different parts of the system can be independently designed according to a sub-specification. This is sometimes known as separation of concerns. However, once the components are machine learning based, tighter coupling becomes a side effect of the learned nature of the system. For example, if a driverless car’s detection of cyclist is dependent on its detection of the road surface, a change in the road surface detection algorithm will have downstream effects on the cyclist detection. Even if the road detection system has been improved by objective measures, the cyclist detection system may have become sensitive to the foibles of the previous version of road detection and will need to be retrained.

Most of our experience with deployment relies on some approximation to the component-based model, this is also important for verification of the system. If the components of the system can be verified then the composed system can also, potentially, be verified.

Computer Science Paradigm Shift

[edit]

The next wave of machine learning is a paradigm shift in the way we think about computer science.

Classical computer science assumes that ‘data’ and ‘code’ are separate, and this is the foundation of secure computer systems. In machine learning, ‘data’ is ‘software’, so the decision making is directly influenced by the data. We are short-circuiting a fundamental assumption of computer science, we are breeching the code/data separation.

This means we need to revisit many of our assumptions and tooling around the machine learning process. In particular, we need new approaches to systems design, new approaches to programming languages that highlight the importance of data, and new approaches to systems security.

Peppercorns

[edit]

Figure: A peppercorn is a system design failure which is not a bug, but a conformance to design specification that causes problems when the system is deployed in the real world with mischievous and adversarial actors.

Asking Siri “What is a trillion to the power of a thousand minus one?” leads to a 30 minute response1 consisting of only 9s. I found this out because my nine year old grabbed my phone and did it. The only way to stop Siri was to force closure. This is an interesting example of a system feature that’s not a bug, in fact it requires clever processing from Wolfram Alpha. But it’s an unexpected result from the system performing correctly.

This challenge of facing a circumstance that was unenvisaged in design but has consequences in deployment becomes far larger when the environment is uncontrolled. Or in the extreme case, where actions of the intelligent system effect the wider environment and change it.

These unforeseen circumstances are likely to lead to need for much more efficient turn-around and update for our intelligent systems. Whether we are correcting for security flaws (which are bugs) or unenvisaged circumstantial challenges: an issue I’m referring to as peppercorns. Rapid deployment of system updates is required. For example, Apple have “fixed” the problem of Siri returning long numbers.

Here’s another one from Reddit, of a Tesla Model 3 system hallucinating traffic lights.

The challenge is particularly acute because of the scale at which we can deploy AI solutions. This means when something does go wrong, it may be going wrong in billions of households simultaneously.

You can also check this blog post on Decision Making and Diversity. and this blog post on Natural vs Artifical Intelligence..

One thing about working in an industrial environment, is the way that short-term thinking actions become important. For example, in Formula One, the teams are working on a two-week cycle to digest information from the previous week’s race and incorporate updates to the car or their strategy.

However, businesses must also think about more medium-term horizons. For example, in Formula 1 you need to worry about next year’s car. So, while you’re working on updating this year’s car, you also need to think about what will happen for next year and prioritize these conflicting needs appropriately.

In the Amazon supply chain, there are equivalent demands. If we accept that an artificial intelligence is just an automated decision-making system. And if we measure in terms of money automatically spent, or goods automatically moved, then Amazon’s buying system is perhaps the world’s largest AI.

Those decisions are being made on short time schedules; purchases are made by the system on weekly cycles. But just as in Formula 1, there is also a need to think about what needs to be done next month, next quarter and next year. Planning meetings are held not only on a weekly basis (known as weekly business reviews), but monthly, quarterly, and then yearly meetings for planning spends and investments.

Amazon is known for being longer term thinking than many companies, and a lot of this is coming from the CEO. One quote from Jeff Bezos that stuck with me was the following.

“I very frequently get the question: ‘What’s going to change in the next 10 years?’ And that is a very interesting question; it’s a very common one. I almost never get the question: ‘What’s not going to change in the next 10 years?’ And I submit to you that that second question is actually the more important of the two – because you can build a business strategy around the things that are stable in time. … [I]n our retail business, we know that customers want low prices, and I know that’s going to be true 10 years from now. They want fast delivery; they want vast selection. It’s impossible to imagine a future 10 years from now where a customer comes up and says, ‘Jeff I love Amazon; I just wish the prices were a little higher,’ [or] ‘I love Amazon; I just wish you’d deliver a little more slowly.’ Impossible. And so the effort we put into those things, spinning those things up, we know the energy we put into it today will still be paying off dividends for our customers 10 years from now. When you have something that you know is true, even over the long term, you can afford to put a lot of energy into it.”

This quote is incredibly important for long term thinking. Indeed, it’s a failure of many of our simulations that they focus on what is going to happen, not what will not happen. In Amazon, this meant that there was constant focus on these three areas, keeping costs low, making delivery fast and improving selection. For example, shortly before I left Amazon moved its entire US network from two-day delivery to one-day delivery. This involves changing the way the entire buying system operates. Or, more recently, the company has had to radically change the portfolio of products it buys in the face of Covid19.

Figure: Experiment, analyze and design is a flywheel of knowledge that is the dual of the model, data and compute. By running through this spiral, we refine our hypothesis/model and develop new experiments which can be analyzed to further refine our hypothesis.

From the perspective of the team that we had in the supply chain, we looked at what we most needed to focus on. Amazon moves very quickly, but we could also take a leaf out of Jeff’s book, and instead of worrying about what was going to change, remember what wasn’t going to change.

We don’t know what science we’ll want to do in five years’ time, but we won’t want slower experiments, we won’t want more expensive experiments and we won’t want a narrower selection of experiments.

As a result, our focus was on how to speed up the process of experiments, increase the diversity of experiments that we can do, and keep the experiments price as low as possible.

The faster the innovation flywheel can be iterated, then the quicker we can ask about different parts of the supply chain, and the better we can tailor systems to answering those questions.

We need faster, cheaper and more diverse experiments which implies we need better ecosystems for experimentation. This has led us to focus on the software frameworks we’re using to develop machine learning systems including data oriented architectures (Borchert (2020);Lawrence (2019);Vorhemus and Schikuta (2017);Joshi (2007)), data maturity assessments (Lawrence et al. (2020)) and data readiness levels (See this blog post on Data Readiness Levels. and Lawrence (2017);The DELVE Initiative (2020))

Data Oriented Architectures

[edit]

In a streaming architecture we shift from management of services, to management of data streams. Instead of worrying about availability of the services we shift to worrying about the quality of the data those services are producing.

Historically we’ve been software first, this is a necessary but insufficient condition for data first. We need to move from software-as-a-service to data-as-a-service, from service oriented architectures to data oriented architectures.

Streaming System

Characteristics of a streaming system include a move from pull updates to push updates, i.e. the computation is driven by a change in the input data rather than the service calling for input data when it decides to run a computation. Streaming systems operate on ‘rows’ of the data rather than ‘columns’. This is because the full column isn’t normally available as it changes over time. As an important design principle, the services themselves are stateless, they take their state from the streaming ecosystem. This ensures the inputs and outputs of given computations are easy to declare. As a result, persistence of the data is also handled by the streaming ecosystem and decisions around data retention or recomputation can be taken at the systems level rather than the component level.

Recommendation: We should consider a major re-architecting of systems around our services. In particular we should scope the use of a streaming architecture (such as Apache Kafka) that ensures data persistence and enables asynchronous operation of our systems.2 This would enable the provision of QC streams, and real time dash boards as well as hypervisors.

Importantly a streaming architecture implies the services we build are stateless, internal state is deployed on streams alongside external state. This allows for rapid assessment of other services’ data.

The philosphy of DOA is also possible with more standard data infrastructures, such as SQL data bases, but more work has to be put into place to ensure that book-keeping around data provenance and origin is stored, as well as approaches for snapshotting the data ecosystem.

[edit]

Apache Flink is a stream processing framework. Flink is a foundation for event driven processing. This gives a high throughput and low latency framework that operates on dataflows.

Data storage is handled by other systems such as Apache Kafka or AWS Kinesis.

stream.join(otherStream)
    .where(<KeySelector>)
    .equalTo(<KeySelector>)
    .window(<WindowAssigner>)
    .apply(<JoinFunction>)

Apache Flink allows operations on streams. For example, the join operation above. In a traditional data base management system, this join operation may be written in SQL and called on demand. In a streaming ecosystem, computations occur as and when the streams update.

The join is handled by the ecosystem surrounding the business logic.

Milan

[edit]

To answer these challenges at Amazon we began the process of constructing software for data oriented architectures. The team built a data-oriented programming language which is now available through MIT license. The language is called Milan.

Tom Borchert

The Principle Engineer behind the Milan architecture has been Tom Borchert.Quoting from Tom Borchert’s blog on Milan:

Milan has three components:

  1. A general-purpose stream algebra that encodes relationships between data streams (the Milan Intermediate Language or Milan IL)

  2. A Scala library for building programs in that algebra.

  3. A compiler that takes programs expressed in Milan IL and produces a Flink application that executes the program.

Component (2) can be extended to support interfaces in additional languages, and component (3) can be extended to support additional runtime targets. Considering just the multiple interfaces and the multiple runtimes, Milan looks a lot like the much more mature Apache Beam. The difference lies in (1), Milan’s general-purpose stream algebra. }

Figure: The Milan Software has a general purpose stream algebra at its core, the Milan IL.

Figure: The Milan Software is designed for building modern AI systems. https://github.com/amzn/milan/

It is through the general-purpose stream algebra that we hope to make significant inroads on the intellectual debt challenge.

The stream algebra defines the relationship between different machine learning components in the wider software architecture. Composition of multiple services cannot occur without a signature existing within the stream algebra. The Milan IL becomes the key information structure that is required to reason about the wider software system.

Context

This deals with the challenges that arise through the intellectual debt because we can now see the context around each service. This allows us to design the relevant validation checks to ensure that accuracy and fairness are maintained. By recompiling the algebra to focus on a particular decision within the system we can also derive new statistical tests to validate performance. These are the checks that we refer to as progression testing. The loss of programmer control means that we can no longer rely on software tests written at design time, we must have the capability to deploy new (statistical) tests after deployment as the uses to which each service is placed extend to previously un-envisaged domains.

Stateless Services

Importantly, Milan does not place onerous constraints on the builders of individual machine learning models (or other components). Standard modelling frameworks can be used. The main constraint is that any code that is not visible to the ecosystem does not maintain or store global state. This condition implies that the parameters of any machine learning model need to also be declared as an input to the model within the Milan IL.

Meta Modelling

Figure: The Emukit software is a set of software tools for emulation and surrogate modeling. https://amzn.github.io/emukit/

Where does machine learning come in? The strategy I propose is that the Milan IL is integrated with meta-modelling approaches to assist in the explanation of the decision-making framework. At their simplest these approaches may be novelty detection algorithms on the data streams that are emerging from a given service. This is a form of progression testing. But we can go much further. By knowing the training data, the inputs and outputs of the individual services in the software ecosystem, we can build meta-models that test for fairness, accuracy not just of individual system components, but short or long cascades of decision making. Through the use of the Milan IL algebra all these tests could be automatically deployed. The focus of machine learning is on the models-that-model-the-models. The meta-models.

In Amazon, our own focus was on the use of statistical emulators, sometimes known as surrogate models, for fulfilling this task. The work we were putting into this route is available through another software package, Emukit, a framework for decision making under uncertainty. With collaborators my current focus for addressing these issues is a form of fusion of Emukit and Milan (Milemukit??). But the nature of this fusion requires testing on real world problem sets. A task we hope to carry out in close collaboration with colleagues at Data Science Africa.

Trading System

[edit]

As a simple example we’ll consider a high frequency trading system. Anne wishes to build a share trading system. She has access to a high frequency trading system which provides prices and allows trades at millisecond intervals. She wishes to build an automated trading system.

Let’s assume that price trading data is available as a data stream. But the price now is not the only information that Anne needs, she needs an estimate of the price in the future.

mlai.write_figure(‘hypothetical-prices.svg’, directory=‘./data-science/’)

Figure: Anne has access to the share prices in the black stream but not in the blue stream. A hypothetical stream is the stream of future prices. Anne can define this hypothetical under constraints (latency, input etc). The need for a model is now exposed in the software infrastructure

Hypothetical Streams

We’ll call the future price a hypothetical stream.

A hypothetical stream is a desired stream of information which cannot be directly accessed. The lack of direct access may be because the events happen in the future, or there may be some latency between the event and the availability of the data.

Any hypothetical stream will only be provided as a prediction, ideally with an error bar.

The nature of the hypothetical Anne needs is dependent on her decision-making process. In Anne’s case it will depend over what period she is expecting her returns. In MDOP Anne specifies a hypothetical that is derived from the pricing stream.

It is not the price stream directly, but Anne looks for future predictions from the price stream, perhaps for price in \(T\) days’ time.

At this stage, this stream is merely typed as a hypothetical.

There are constraints on the hypothetical, they include: the input information, the upper limit of latency between input and prediction, and the decision Anne needs to make (how far ahead, what her upside, downside risks are). These three constraints mean that we can only recover an approximation to the hypothetical.

Hypothetical Advantage

What is the advantage to defining things in this way? By defining, clearly, the two streams as real and hypothetical variants of each other, we now enable automation of the deployment and any redeployment process. The hypothetical can be instantiated against the real, and design criteria can be constantly evaluated triggering retraining when necessary.

SafeBoda

[edit]

The complexity of building safe, maintainable systems that are based on interacting components which include machine learning models means that smaller companies can be excluded from access to these technologies due the technical and intellectual debt incurred when maintaining such systems in a real-world environment.

Figure: SafeBoda is a ride allocation system for Boda Boda drivers. Let’s imagine the capabilities we need for such an AI system.

SafeBoda is a Kampala based rider allocation system for Boda Boda drivers. Boda boda are motorcycle taxis which give employment to, often young men, across Kampala. Safe Boda is driven by the knowledge that road accidents are set to match HIV/AIDS as the highest cause of death in low/middle income families by 2030.

With road accidents set to match HIV/AIDS as the highest cause of death in low/middle income countries by 2030, SafeBoda’s aim is to modernise informal transportation and ensure safe access to mobility.

A key aim of the AutoAI agenda is to reduce these technical challenges, so that such software can be maintained safely and reliably by a small team of software engineers. Without this capability it is hard to imagine how low resource environments can fully benefit from the ‘data revolution’ without heavy reliance on technical provision from high-resource environments. Such dependence would inevitably mean a skew towards the challenges that high-resource economies face, rather than the more urgent and important problems that are faced in low-resource environments.

Let’s consider a ride sharing app, for example the SafeBoda system.

Anne is on her way home now; she wishes to hail a car using a ride sharing app.

The app is designed in the following way. On opening her app Anne is notified about drivers in the nearby neighborhood. She is given an estimate of the time a ride may take to come.

Given this information about driver availability, Anne may feel encouraged to enter a destination. Given this destination, a price estimate can be given. This price is conditioned on other riders that may wish to go in the same direction, but the price estimate needs to be made before the user agrees to the ride.

Business customer service constraints dictate that this price may not change after Anne’s order is confirmed.

In this simple system, several decisions are being made, each of them on the basis of a hypothetical.

When Anne calls for a ride, she is provided with an estimate based on the expected time a ride can be with her. But this estimate is made without knowing where Anne wants to go. There are constraints on drivers imposed by regional boundaries, reaching the end of their shift, or their current passengers mean that this estimate can only be a best guess.

This best guess may well be driven by previous data.

Ride Sharing: Service Oriented to Data Oriented

[edit]

Figure: Service oriented architecture. The data access is buried in the cost allocation service. Data dependencies of the service cannot be found without trawling through the underlying code base.

The modern approach to software systems design is known as a service-oriented architectures (SOA). The idea is that software engineers are responsible for the availability and reliability of the API that accesses the service they own. Quality of service is maintained by rigorous standards around testing of software systems.

Figure: Data oriented architecture. Now the joins and the updates are exposed within the streaming ecosystem. We can programmatically determine the factor graph which gives the thread through the model.

In data driven decision-making systems, the quality of decision-making is determined by the quality of the data. We need to extend the notion of service-oriented architecture to data-oriented architecture (DOA).

The focus in SOA is eliminating hard failures. Hard failures can occur due to bugs or systems overload. This notion needs to be extended in ML systems to capture soft failures associated with declining data quality, incorrect modeling assumptions and inappropriate re-deployments of models. We need to focus on data quality assessments. In data-oriented architectures engineering teams are responsible for the quality of their output data streams in addition to the availability of the service they support (Lawrence, 2017). Quality here is not just accuracy, but fairness and explainability. This important cultural change would be capable of addressing both the challenge of technical debt (Sculley et al., 2015) and the social responsibility of ML systems.

Software development proceeds with a test-oriented culture. One where tests are written before software, and software is not incorporated in the wider system until all tests pass. We must apply the same standards of care to our ML systems, although for ML we need statistical tests for quality, fairness, and consistency within the environment. Fortunately, the main burden of this testing need not fall to the engineers themselves: through leveraging classical statistics and emulation we will automate the creation and redeployment of these tests across the software ecosystem, we call this ML hypervision.

Modern AI can be based on ML models with many millions of parameters, trained on very large data sets. In ML, strong emphasis is placed on predictive accuracy whereas sister-fields such as statistics have a strong emphasis on interpretability. ML models are said to be ‘black boxes’ which make decisions that are not explainable.3

Figure: Data-oriented programing. There is a requirement for an estimate of the driver allocation to give a rough cost estimate before the user has confirmed the ride. In data-oriented programming, this is achieved through declaring a hypothetical stream which approximates the true driver allocation, but with restricted input information and constraints on the computational latency.

For the ride sharing system, we start to see a common issue with a more complex algorithmic decision-making system. Several decisions are being made multiple times. Let’s look at the decisions we need along with some design criteria.

  1. Driver Availability: Estimate time to arrival for Anne’s ride using Anne’s location and local available car locations. Latency 50 milliseconds
  2. Cost Estimate: Estimate cost for journey using Anne’s destination, location and local available car current destinations and availability. Latency 50 milliseconds
  3. Driver Allocation: Allocate car to minimize transport cost to destination. Latency 2 seconds.

So we need:

  1. a hypothetical to estimate availability. It is constrained by lacking destination information and a low latency requirement.
  2. a hypothetical to estimate cost. It is constrained by low latency requirement and

Simultaneously, drivers in this data ecosystem have an app which notifies them about new jobs and recommends them where to go.

Further advantages. Strategies for data retention (when to snapshot) can be set globally.

A few decisions need to be made in this system. First of all, when the user opens the app, the estimate of the time to the nearest ride may need to be computed quickly, to avoid latency in the service.

This may require a quick estimate of the ride availability.

Information Dynamics

[edit]

With all the second guessing within a complex automated decision-making system, there are potential problems with information dynamics, the ‘closed loop’ problem, where the sub-systems are being approximated (second guessing) and predictions downstream are being affected.

This leads to the need for a closed loop analysis, for example, see the “Closed Loop Data Science” project led by Rod Murray-Smith at Glasgow.

Thanks!

For more information on these subjects and more you might want to check the following resources.

Borchert, T., 2020. Milan: An evolution of data-oriented programming.
Brooks, F., n.d. The mythical man-month. Addison-Wesley.
Joshi, R., 2007. A loosely-coupled real-time SOA. Real-Time Innovations Inc.
Lawrence, N.D., 2019. Modern data oriented programming.
Lawrence, N.D., 2017. Data readiness levels. ArXiv.
Lawrence, N.D., Montgomery, J., Paquet, U., 2020. Organisational data maturity. The Royal Society.
Sculley, D., Holt, G., Golovin, D., Davydov, E., Phillips, T., Ebner, D., Chaudhary, V., Young, M., Crespo, J.-F., Dennison, D., 2015. Hidden technical debt in machine learning systems, in: Cortes, C., Lawrence, N.D., Lee, D.D., Sugiyama, M., Garnett, R. (Eds.), Advances in Neural Information Processing Systems 28. Curran Associates, Inc., pp. 2503–2511.
The DELVE Initiative, 2020. Data readiness: Lessons from an emergency. The Royal Society.
Vorhemus, C., Schikuta, E., 2017. A data-oriented architecture for loosely coupled real-time information systems, in: Proceedings of the 19th International Conference on Information Integration and Web-Based Applications & Services, iiWAS ’17. Association for Computing Machinery, New York, NY, USA, pp. 472–481. https://doi.org/10.1145/3151759.3151770
